30V 100A 3000W Adjustable Switch Power Supply 110V Input

30V 100A 3000W Adjustable Switch Power Supply 110V Input

Tap to enlarge

12345

5.0 average, based on 2 reviews

$1,600.00$1,049.95


Product Information
Specification

VOLTEQ HY30100EX is a high current, high voltage regulated DC power supply with built-in over-voltage and over-current protection, ideal for battery charging, DC motors, anodizing and plating applications. HY30100EX is one of the most powerful DC power supply we carry, with the maximum DC power of 3000W. This high quality regulated power supply can be continuously adjustable at 0-30V DC and 0-100A. The unit comes with 2 LED displays, providing accurate and clearly visible readout for the voltage and current value. This unit works with 110V input, and comes with a NEMA plug. At maximum output (30V and 100A) the unit will draw 34A on the AC line, so if you plan to use this unit for maximum output, you need to ensure AC line with current ratings of 34A or more. We also have this same unit with 220-240V input. Retails well over $1400. Please email us with any questions!



Features & Specifications:


  • Two level of control for both current and voltage outputs: coarse and fine for ease of use
  • Outputs: 0-30 V and 0-100 A
  • Protection: over-voltage and over-current protection
  • Input voltage: 110V -120V AC
  • Voltage Stabilization: <=0.2%
  • Current Stabilization: <=0.5%
  • Load Regulation: <=0.3%
  • Ripple noise: CV <= 1%
  • LCD reading accuracy: +/-1% +/-1 digit
  • Environment: 0-40C, relative humidity < 90%
  • Warranty: 1 year
 Switching Power Supply HY30100EX
 Switching Power Supply HY30100EX
 Switching Power Supply HY30100EX
 Switching Power Supply HY30100EX
 Switching Power Supply HY30100EX
Product CodeHY30100EX_110V
ManufacturerVOLTEQ
Stock Level3
ConditionNew
Weight20.22lb
Width10.75″
Height6.3″
Depth16.25″

Customer Reviews

Average Rating: 5

12345
Works great for our experiment. Thanks Volteq.Justin W. (7 Oct 2019, 12:01)

12345
We must have bought over a dozen of these over the years. Works great for our plating work. They did get rusty and go bad.Joseph C (6 Aug 2016, 17:12)
