Programmable DC Power Supply HY1550EP 0-15V 0-50A

Programmable DC Power Supply HY1550EP 0-15V 0-50A

Tap to enlarge

$800.00$449.95

(Quantity discounts available)


Product Information
Specification
Quantity Discounts




Volteq HY1550EP is a programmable DC power supply with built-in Arduino Micro controller. If you are familiar with Arduino, writing software code to control this power supply to run automatic testing is a piece of cake. We supply a sample code with rich set of features including ramping, amp-minute metering, remote sensing, active feedback control, etc. This power supply is ideally suited for automatic testing, battery charging/maintenance, DC/servo motors, anodizing and plating applications. We also provide up to 14 output/input pins for external data collection and control.


Key Features & Specifications:

  • 4 Lines 20 characters LCD display
  • Active feedback for more stable output
  • Remote sensing
  • Amp-minute metering and control
  • Timer control
  • Voltage ramp
  • Automatic battery charger
  • Digital Voltmeter
  • Transient measurement
  • 6 Groups of memories
  • 4 Function keys (F1-F4) and 10 user definable keys (M1 - M10)
  • Control: digital control via front panel or via USB
  • Output enable and disable
  • Two level of control for both current and voltage outputs: coarse and fine for ease of use
  • Outputs: 0-15 V and 0-50 A
  • Protection: over-voltage protection
  • Input voltage: 110V AC and 220V AC switchable
  • Voltage Stabilization: <=0.2%
  •  Current Stabilization: <=0.5%
  • Load Regulation: <=0.3%
  • Ripple noise: CV <= 1%
  • Environment: 0-40C, relative humidity < 90%
  • Size: 15.8" x 10" x 6"
  • Weight: 18 lbs
  • Warranty: 1 year
Switching Power Supply HY1550EP
Switching Power Supply HY1550EP
 Switching Power Supply HY1520EX
 Switching Power Supply HY1520EX
Product CodeHY1550EP
ManufacturerVOLTEQ
Stock Level15
ConditionNew
Weight15lb
Width10″
Height6.25″
Depth14.25″
