Siglet SDG1025 25MHz Function / Arbitrary Waveform Generator

Features:

• Advanced DDS technology, 2 analog channels output, 25 MHz maximum output frequency
• 125 MSa/s of sample rate, 14 bits of vertical resolution, 16k points of memory depth
• Intuitive user interface with 3.5" color LCD display
• DDS technology: Output signals become more accurate and stable with lower distortion
• 5 standard waveforms: Sine, Square, Ramp, Pulse, Noise
• Arbitray waveform defined by user
• Versatile modulation and variety of waveforms: AM, FM, PM, ASK, FSK, Sweep, Burst, PWM, and DSB-AM
• USB Host, to support USB disk storage
• Versatile input and output: External modulation source, External clock reference (10 MHz), External trigger input, waveforms output, synchronous signal output
• Support seamless connection  with Siglent digital oscilloscopes, which allows direct read and rebuild of the stored waveform in the oscilloscopes
• Support USB storage device
• High accuracy and wide band width frequency counter range up to 200 MHz
• 3 year warranty
