HY061000EX High Current Electroplating Rectifier 0-6V DC, 0-1000A

HY061000EX High Current Electroplating Rectifier 0-6V DC, 0-1000A

Tap to enlarge


5.0 average, based on 2 reviews


Product Information


New Design! VOLTEQ HY061000EX is a high current electroplating rectifier with built-in over-voltage and over-current protection, ideal for anodizing and plating applications in commercial metal finishing shops, as well as battery charging and DC motors. HY061000EX is one of the most powerful variable DC power supply we carry, with the maximum DC power of 6000W. This high quality plating rectifier can be continuously adjustable at 0-6V DC and 0-1000A. The current requirement on the AC line is 31A at maximum output of 6000W. Retails well over $5000.


Got a question? Call us at 408-622-9851.

Features & Specifications:

  • Easy control of both current and voltage outputs using a remote control box
  • Timer and alarm function allows easy control of process
  • Outputs: 0-6 V and 0-1000 A
  •  Protection: over-voltage and over-current protection
  • Input voltage: 220V -240V AC single phase (No NEMA plug included)
  • Voltage Stabilization: <=0.5%
  •  Current Stabilization: <=1%
  • Load Regulation: <=0.5%
  • Ripple noise: CV <= 5%
  • LCD reading accuracy: +/-1% +/-1 digit
  • Replaceable filter on fans
  • Environment: 0-40C, relative humidity < 90%; no condensation
  • Size: 19" W x 25.25"L x 9.5"H
  • Weight: 95 lbs
  • Warranty: 1 year
1000A DC Power Supply HY061000EX
1000A Plating Power Supply HY061000EX
1000A Plating Rectifier HY061000EX
Product CodeHY061000EX
Stock Level14

Customer Reviews

Average Rating: 5

Didn't think we would use the timer, but it turned out to be quite useful.Cory K (5 May 2023, 13:43)

Great price for a 1000A plater, can't beat that.Steven W (5 Mar 2020, 06:43)
